-20,000 lb. Capacity Heavy Duty Conveyor
-26" Wide Mult Capacity
-72" Coil O.D. Max.
Consisting of the following:
-Downlayer:
5" Dia. x 75" Face Driven Rolls
Hydraulic Motor Drive
Right Angle Discharge
25" Long Horn Extension
(1) - 2.5" Bore x 26" Stroke Hyd. Horn Cylinder
(2) - 5" Bore x 23" Stroke Hyd. Tilt Cylinders
Approx. 74" from floor to top of horn in "tipped" position
34.5" Passline Height
-Manual Banding Table:
5" Dia. Driven Rolls
Hydraulic Motor Driven Rolls
3 Arm Type Coil Lift and Rotate
(1) - 6" Bore x 9" Stroke Hyd. Lift Cylinder
Hydraulic Motor Rotate
35" Passline Height
-Coil Storage Conveyor:
25' Long
5.25" Dia. x 74" Face Driven Rolls
10 HP Foote-Jones AC Gear Motor Drive, 230/460 V
35" Passline Height
-Mechanical Drawings included
