Specifications
| Load Weight |
4000 pounds |
| Dimensions |
120"L X 83"H X 65"W |
| Weight |
2100 pounds |
Equipped With
MODEL ..................... SYNERGY 3 LP
SERIAL .................... A390-010-0155
MACHINE JOB # ............. MCJ1555
LOAD MAX WEIGHT ........... 4000 LBS.
CONTROL OPTIONS ........... MANUAL/AUTO
MAX PALLET SIZE ........... 50" X 50" X 80"
TURN TABLE DIAMETER ....... 57"
TURN TABLES SPEED ......... 0-10 RPM
SPIRAL ELEVATOR SPEED ..... FULLY ADJUSTABLE
SPIRAL MOTOR .............. 1/2HP
FILM DELIVERY ............. POWERED HYDRO-STRETCH
LOAD COMPRESSON ........... FULLY ADJUSTABLE
PALLET HEIGHT SENSOR ...... AUTOMATIC PHOTO ELECTRIC EYE
VOLTS ..................... 115V
FLOOR SPACE ............... 70" X 128" X 84" INCLUDES RAMP
