Feed Line, Servo, Dallas, 72" x 0.060" STOCK# 3943

Brand
Not Specified

Model

Stock #
3943

Condition
Good

Year

Location
Toledo, Ohio
United States

Specifications

Equipped With

-Dallas DJR-20,000# x 72" Coil Reel:
  Serial Number:  20212
  20,000 lbs.
  72" Wide
  20" - 24" ID
  72" Max. OD
  Powered Jog Forward and Reverse
  6 Keepers

-20,000# Dallas LC-20,000# x 72" Coil Lift:
  Serial #20213
  42" Min. OD
  72" Max OD
  18" Lift Height

-Dallas DPS-4 1/4-7-72 Powered Straightener:
  Serial #20215
  72" x 0.060" Mild Steel
  48" x 0.125" Mild Steel Capacity
  7 Straightening Rolls, 4.25" Diameter Rolls
  Entry and Exit Pinch Rolls
  Coil Restrictor-Debender, Peeler-Threader
  Dual Exit Threading Tables
  Hand Held Pendant
  Sona-Trol Loop Eye

-Dallas DRF-672 Servo Feed:
  Serial Number:  20217
  72" x 0.060" Mild Steel
  48" x 0.125" Mild Steel Capacity
  6" Diameter Feed Rolls
  Control Updated in 2015 DRF Control 900E
  Hand Held Pendant
  Adjustable Cabinet Base
  480V / 3 PH / 60 HZ
  Right to Left Direction

-Approx. Weight:  18,000 lbs.
