-S.O. No. 2480
-8" Dia. x 55" Face Arbors w/1" x 3/16" keyway
-Entry Passline Rolls
-Entry Side Guides, individual manual adjustment
-Entry Passline Rolls
-Side Guide Table pivots open for Tooling change
-Powered Parallel Arbor Adjstment by AC Motor
-Powered Outboard Arbor Support in/out by AC Motor
-Pasline: 38"
-Approx. 35 HP DC Motor Driven, 400/1600 RPM, 230 V
Thru Right Angle Reducer
-Tooling: 0.500" Wide Knives Included, No Spacers.
-Line Direction: Right to Left
-Overall Size: Slitter Head: 176" L x 56" W x 88" High
Drive: 110" L x 57" W x 58" High
