-Material Width:                 48" Nominal

-Material Thickness:             0.018" to 0.040"

-Material Yield:                 50,000 PSI

-Work Roll Number:               17 Rolls, 8 Up, 9 Down

-Work Roll Size:                 0.875" Diameter x 54" Face, 4 HI

-Work Roll Centers:              1"

-Backup Adjustment:              Hydraulic

-Backup Flights:                 Top:  9

                                 Bottom:  9

-Entry Pinch Rolls:              Upper Steel / Lower Urethane Covered

-Main Drive:                     30 HP, 1760 RPM, 230/460 V, Variable Frequency AC

-Line Speed:                     120 FPM Maximum

-Line Direction:                 Right to Left

-Passline Height:                42"

-Approx. Overall Size:           110" L x 60" W x 70" High
