Specifications
Equipped With
CAPACITY ................. 26" X 26"
BLADE SIZE ............... 25' X 2" X .063"
BLADE SPEED .............. 40-300 FPM (INFINITELY VARIABLE)
BLADE GUIDES ............. CARBIDE
BLADE WHEEL DIAMETER ..... 32"
BLADE DRIVE .............. 10 H.P. (VARIABLE FREQUENCY DRIVE)
HYDRAULIC MOTOR .......... 3 H.P.
HYDRAULIC SYSTEM ......... 1,200 P.S.I.
HYDRAULIC TANK CAPACITY .. 9 GALLONS
COOLANT TYPE ............. FLOOD
COOLANT TANK ............. 10.5 GALLONS
SHUTTLE STROKE ........... 0-28" WITH MULTI INDEXNG
VISE CONTROL ............. HYDRAULIC
TABLE HEIGHT ............. 31"
MAXIMUM WORK LOAD ........ 30,000 LBS.
VOLTAGE .................. 460
PHASE .................... 3
DIMENSIONS ............... 155" X 89" X 120" (SAW ONLY)
WEIGHT ................... 24,000 LBS. (SAW ONLY)
EQUIPPED WITH:
40' OF POWERED CHAIN DRIVE ROLLER CONVEYOR (2) 20' SECTIONS 30" WIDE
PLC 100
FULL CAPACITY OVERHEAD BUNDLING CLAMPS
OUT OF STOCK SWITCH
BLADE BREAKAGE SWITCH
INVERTER DRIVE
HEAD HEIGHT SETTING
FLOOD COOLANT
COOLANT WASH DOWN HOSE
POWERED BLADE CHIP BRUSH
